||B1: 1999.00 EA|
Physical: Some light scratches - Excellent Condition
Electrical: Meets or exceeds original specs, all functions operate
Call for availability
File Photo for Representation of item. May not be the actual item offered for sale.
200 watts minimum sine wave continuous average power output, per channel, both channels operating into 1 ohm, 2 ohms, 4 ohms, or 8 ohms load impedance, which is:
14.1 volts RMS across 1 ohm
20.0 volts RMS across 2 ohms
28.3 volts RMS across 4 ohms
40.0 volts RMS across 8 ohms
400 watts minimum sine wave continuous average power output into 0.5 ohm, 1 ohm, 2 ohms, or 4 ohms load impedance, which is:
14.1 volts RMS across 0.5 ohm
20.0 volts RMS across 1 ohm
28.3 volts RMS across 2 ohms
40.0 volts RMS across 4 ohms
OUTPUT LOAD IMPEDANCE
1 ohm, 2 ohms, 4 ohms, and 8 ohms; separate terminals are provided for each output
0.5 ohm, 1 ohm, 2 ohms, and 4 ohms; obtained by connecting together the appropriate terminals of both channels
RATED POWER BAND
20 Hz to 20,000 Hz
TOTAL HARMONIC DISTORTION
0.1% maximum harmonic distortion at any power level from 250 milliwatts to 200 watts per channel from 20 Hz to 20,000 Hz, both channels operating
0.1% maximum harmonic distortion at any power level from 250 milliwatts to 400 watts from 20 Hz to 20,000 Hz INTERMODULATION DISTORTION
0.1% maximum if instantaneous peak power output is 400 watts or less per channel with both channels operating for any combination of frequencies, 20 Hz to 20,000 Hz
0.1% maximum if instantaneous peak power output is 800 watts or less for any combination of frequencies, 20 Hz to 20.000 Hz
FREQUENCY RESPONSE (at one watt output)
20 Hz to 20,000 Hz, +0 -0.25 dB
10 Hz to 100,000 Hz +0 -3.0 dB
NOISE AND HUM
95 dB below rated output
25 volts for distribution lines
16 at 1 ohm output, 50 at 2 ohms output, 30 at 4 ohms output, 16 at 8 ohms output
16 at 0.5 ohms, 50 at 1 ohm, 30 at 2 ohms, and 16 at 4 ohms output
Switchable: 0.75 volt or 2.5 volts-Level control provided for higher input voltages
120 volts 50/60 Hz, 70 to 550 watts
49 silicon transistors
45 silicon rectifiers and diodes
8 integrated circuits
Front panel measures 16-3/16 inches wide (41.1cm) by 7-1/8 inches high (18.1 cm). Chassis measures 14-3/4 inches deep (37.5 cm) by 6-1/2 inches high (16.5 cm) by 14-1/2 inches deep (36.8 cm), including connectors. Knob clearance required is 1-1/4 inches (3.2 cm) in front of mounting panel
Front panel is anodized gold and black with special gold/ teal nomenclature illumination. Chassis is chrome and black
84 pounds (38.1 kg) net, 98 pounds (44.5 kg) in shipping carton
200 WPC with meters, Power Guard, Chrome Chassis.|
Designed by Ron Evans.
Shipping weight: 105 lbs.|
